Data lists
5.3 signals
Basic logic functions: Spindles (S1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
101
5.3 signals
5.3.1 Signals to axis/spindle
DB number Byte.bit Description
31, ... 0.7 - 0.0 Feedrate override H to A
31, ... 1.3 Axis/spindle disable
31, ... 1.4 Followup mode
31, ... 1.5 Position measuring system 1
31, ... 1.6 Position measuring system 2
31, ... 1.7 Override active
31, ... 2.1 Servo enable
31, ... 2.2 Spindle reset/delete distancetogo
31, ... 3.6 Velocity/spindle speed limitation
31, ... 3.7 Program test Axis/Spindle Enable
31, ... 16.2-16.0 Actual gear step A to C
31, ... 16.3 Gear changed
31, ... 16.4 Resynchronize spindle 1
31, ... 16.5 Resynchronize spindle 2
31, ... 16.6 no n-monitoring with gear change
31, ... 16.7 Delete S value
31, ... 17.0 Feedrate override for spindle valid
31, ... 17.4 Resynchronize spindle during positioning 1
31, ... 17.5 Resynchronize spindle during positioning 2
31, ... 17.6 Invert M3/M4
31, ... 18.4 Oscillation via PLC
31, ... 18.5 Oscillation enable (oscillation speed)
31, ... 18.6 Oscillation rotation direction clockwise (Set rotation direction clockwise)
31, ... 18.7 Oscillation rotation direction counterclockwise (Set rotation direction counterclockwise)
31, ... 19.7 - 19.0 Spindle offset H to A
31, ... 30.0 Spindle stop
31, ... 30.1 Spindle start CW
31, ... 30.2 Spindle start CCW
31, ... 30.3 Automatic gear step change
31, ... 30.4 Spindle positioning
31, ... 60.0 Spindle/No Axis
31, ... 60.2 Encoder limit frequency exceeded 1
31, ... 60.3 Encoder limit frequency exceeded 2
31, ... 60.4 Homed/synchronized 1
31, ... 60.5 Homed/synchronized 2
