Siemens SINUMERIK 840D sl Function Manual

Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
69
2.4.4.4 Suppression of frames
Programming
Comman
d
Significance
G53
Nonmodal suppression of the following frames:
• System frame for cycles
• Programmable frame
• System frame for transformations, workpieces, TOROT and TOFRAME
• Active settable frame
G153
Nonmodal suppression of the following frames:
• System frame for cycles
• Programmable frame
• System frame for TOROT and TOFRAME, workpieces
• Active settable frame
• All channel-specific and NCU global basic frames
• System frames for PAROT, PRESET, scratching, ext. ZO
SUPA
Implicit preprocessing stop and non-modal suppression of frames analog G153 and
additional
• handwheel offsets (DRF)
• [ext. Zero offset]
• Overlaid motion
G500
Modal activation of the G500 frame. The G500 frame should be a zero frame.
DRFOF
Deactivate (clear) the handwheel offsets (DRF)

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
