Basic logic functions: Emergency Stop (N2)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

Data lists

5.1 Machine data

5.1.1 Drive-specific machine data

Number Identifier: $MD_ Description

1404 PULSE_SUPPRESSION_DELAY Time for pulse suppression

5.1.2 Axis/spindlespecific machine data

Number Identifier: $MA_ Description

36610 AX_EMERGENCY_STOP_TIME Length of the braking ramp for error states

36620 SERVO_DISABLE_DELAY_TIME Cutout delay servo enable

5.2 Signals

5.2.1 Signals to NC

DB number Byte.Bit Description

10 56.1 EMERGENCY STOP

10 56.2 Acknowledge EMERGENCY STOP
