Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
127
2.12.4.1 General PI services
The possible services are described in this section.
PI service: ASUB
Allocate function interrupt:
A program stored on the NCK is assigned an interrupt signal for a channel. This is possible
only if the file may be executed. The path name and program name must be entered as
described in the Programming Manual Job Planning, File and Program Management,
Section "Program Memory"). Please also refer to example of FB 4 for notation of path and
program names.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.ASUP Assign interrupt
Unit INT 1 to 10 Channel
WVar1 WORD 1 to 8 Interrupt number
WVar2 WORD 1 to 8 Priority
WVar3 WORD 0/1 LIFTFAST
WVar4 WORD 0/1 BLSYNC
Addr1 STRING Path name
Addr2 STRING Program name
Note
The SETINT instruction is also used to make the assignment.
The ASUP PI service may only be executed when the channel to be activated is in RESET
state.
References:
/PGA/ Programming Manual Job Planning, Flexible NC-Programming Chapter "Interrupt
routine (SETINT, DISABLE, ENABLE, CLRINT)".
PI service: CANCEL
Execute the function Cancel:
The CANCEL command activates the Cancel function (in the same way as the key on the
HMI).
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CANCEL Cancel
