Siemens SINUMERIK 840D sl Function Manual

Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
145
PI service: TRESMO
Function Reset monitoring values:
This PI service resets the monitoring values of the designated edges of the designated tools
to their setpoint (initial) values.
This only relates to tools with active monitoring.
Compare this with the RESETMON NC command.
Parameterization
Signal Type Value range Description
PIService ANY PI. TRESMO Reset monitoring values
Unit INT 1 to 10 TO area
WVar1 WORD -max ..max ToolNumber
0: Applies to all tools
>0: Applies only to this tool
<0: Applies to all sister tools of the specified T No.
WVar2 WORD 0 ... max. D number
>0: Monitoring of specified edge of specified tools is reset.
0: Monitoring of all edges of specified tools is reset.
WVar3 WORD 0 ...15 Monitoring types
Type of monitoring to be reset.
This parameter is binary-coded.
1: Tool-life monitoring is reset.
2: Count monitoring is reset.
4: Wear monitoring is reset.
8: Sum offset monitoring is reset.
Combinations of monitoring types can be reset by adding
the values above.
0: All active tool-monitoring functions ($TC_TP9) are reset.
