Detailed description

2.3 Starting up hardware configuration of PLC CPUs

Basic logic functions: PLC basic program solution line (P3 sl)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

Note

On SINUMERIK 840D, SIMATIC line 0 is allocated for the SINUMERIK components. In this

line stretches to:

• Slot 2 the integrated PLC with the different bus systems

• Slot 3, empty

• Slot 4 the NCK 840D sl. The properties (I/O-address 256, process alarm) of the NCK

must not be changed, as process interrupts (e.g. auxiliary functions) of the NCK to PLC

may, in this case, no longer function.

• Slot 5 the integrated Ethernet CP 840D sl

• Slot 6 the integrated HMI 840D sl

The integrated drive is linked on the internal PCI bus (PROFIBUS protocol).

Currently, this bus does not support I/O access, and SFCs are not supported for this bus.

If you are using a different NCU, you can change the NCU using drag & drop. The settings

remain unaffected. When using the program "Starter" the icon "SINAMICS_in_NCUxyz" is

also to be deleted and created again after the exchange of the NCU in the SIMATIC

Manager.

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
