Detailed Description
2.5 Toolholder with orientation capability
Basic logic functions: Tool Offset (W1)
118 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Note
The tool orientation is not bound strictly to the frame orientation. When a frame is active and
G code TCOABS is active, you can select a tool, whereby the orientation of the tool is
independent of the orientation of the active frame.
Following tool selection, you can change the frame, which does not affect the components of
tool length compensation. It is then no longer certain that the tool is positioned perpendicular
to the machining plane. You should therefore first check that the intended tool orientation is
maintained on an inclined surface.
When TCOFR, etc., is active, the tool orientation used in the tool length calculation is always
determined from the active frame each time the toolholder is changed.
Toolholder from G code of group 53
The G codes of group 53 (TOFRAME, TOROT, etc.) can be used to define a frame such that
an axis direction (Z, Y or X) in this frame is equal to the current tool orientation.
The G code of group 6 (G17 - G19), which is active at the time TOFRAME is called,
determines the tool orientation.
If no toolholder is active, or if a toolholder is active but does not cause the tool orientation to
change, the Z direction in the new frame is:
The same as the old Z direction with G17
The same as the old Y direction with G18
The same as the old X direction with G19.
These directions are modified accordingly for rotating toolholders. The same applies to the
new X and Y directions.
Instead of TOFRAME or TOROT, one of the G codes TOFRAMEX, TOFRAMEY, TOROTX, or
TOROTY can be used. The meanings of the axes are interchanged accordingly.
Group change
Changing the G code from group 42 (TCOABS, TCOFR, etc.) causes recalculation of the tool
length components.
The (programmed) angles of rotation stored in the toolholder data are not affected, with the
result that the angles originally stored in the toolholder data are reactivated on a change
from TCOFR to TCOABS.
Read rotary angle (α
1
or α
2
):
The angles currently used to calculate the orientation can be read via system variable
$P_TCANG[n] where n = 1 or n = 2.
If two permissible solutions (i.e., a second valid pair of angles) are available for a particular
orientation, the values can be accessed with $P_TCANG[3] or $P_TCANG[4]. The number of
valid solutions 0 to 2 can be read with $P_TCSOL.
