Siemens SINUMERIK 840D sl Function Manual

Detailed Description
2.9 Sum offsets and setup offsets
Basic logic functions: Tool Offset (W1)
150 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DL programming
The sum offset is always programmed relative to the active D number with the command:
DL = "n"
The sum offset "n" is added to the wear of the active D number.
Note
If you use "setup offset" and "sum offset fine", both compensations are combined and added
to the tool wear.
The sum offset is deselected with the command:
DL = 0
Note
DL0 is not allowed. If compensation is deselected (D0 and T0), the sum offset also becomes
ineffective.
Programming a sum offset that does not exist triggers an alarm, similar to programming a D
compensation that does not exist.
Thus, only the defined wear remains part of the compensation (defined in system variables
$TC_DP12 to $TC_DP20).
Programming a sum offset when a D compensation is active (also applies to deselection)
has the same effect on the path as programming a D command. An active radius
compensation will, therefore, lose its reference to adjacent blocks.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
