Siemens SINUMERIK 840D sl Function Manual

Detailed Description
2.14 Reference point approach (R1)
Basic logic functions: NC/PLC interface signals (Z1)
114 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB31, ...
DBX60.5 Referenced/synchronized 2
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
Axes:
When being referenced, if the machine axis has reached the reference point (incremental
measuring systems) or the target point (for length measuring system with distance-coded reference
marks), then the machine axis is referenced and the following interface signal is set:
DB31, ... DBX60.5 (referenced/synchronized 2)
(depending on which position measuring system is active when referencing).
Spindles:
After power-on, a spindle is synchronized the latest after one spindle revolution (260 degrees) (the
zero mark passed or the Bero responded).
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 2 is not referenced/synchronized.
Axes:
Alarm 21610 was output.
Spindles:
Encoder limit frequency exceeded.
Corresponding to .... DB31, ... DBX1.6 (position measuring system 2)
MD34102 $MA_REFP_SYNC_ENCS (measuring system calibration) = 0
Additional references /FB1/ Functions Manual Basic Functions; Spindles (S1)

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
