Siemens SINUMERIK 840D sl Function Manual

Brief description
1.2 Overview of auxiliary functions
Basic logic functions: Auxiliary Function Output to PLC (H2)
12 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
F functions
F (feedrate)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
- - - - - - 0.001 - 999 999.999 REAL Path feed 6
Remarks:
- - -
Application
Path velocity.
Remarks
• F-function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)
FA functions
FA (axial feedrate)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
1 - 31 Axis number 0.001 - 999 999.999 REAL Axial feedrate 6
Remarks:
- - -
Application
Axial velocity.
Remarks
• F-function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
