11.03 3 Safety-Related Functions
3.7 Safe software cams (SN)
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
3-123
Note
The appropriate signals should be accordingly processed by the PLC in the
drive monitoring channel (refer to Chapter 3.9.2, "Signal processing for the
drive monitoring channel").
For safe evaluation of the cam signals, the SGA "axis safely referenced" must
be taken into account.
The SGA "axis safely referenced" can be logically combined using the SGA
"SBH/SG active" if the signal is used to enable a protective zone (refer to
Chapter 7, "Circuit examples for Safety Integrated")
Advantage:
An AND logic operation in the NCK monitoring channel can then be
implemented by means of machine data (refer to Chapter 4, "Machine data
for SINUMERIK 840D").
3.7.3 Overview of machine data for the SN function
Table 3-50 Overview of machine data for 840D
Number Name
36901 $MA_SAFE_FUNCTION_ENABLE
36905 $MA_SAFE_MODULO_RANGE (from SW4.2)
36936 $MA_SAFE_CAM_POS_PLUS[n]
36937 $MA_SAFE_CAM_POS_MINUS[n]
36940 $MA_SAFE_CAM_TOL
36988 $MA_SAFE_CAM_PLUS_OUTPUT[n]
36989 $MA_SAFE_CAM_MINUS_OUTPUT[n]
Note:
Data is described in Chapter 4, "Machine data for SINUMERIK 840D"
Table 3-51 Overview of machine data for 611 digital
Number Name
1301 $MD_SAFE_FUNCTION_ENABLE
1305 $MD_SAFE_MODULO_RANGE (840D from SW4.2)
1336 $MD_SAFE_CAM_POS_PLUS[n]
1337 $MD_SAFE_CAM_POS_MINUS[n]
1340 $MD_SAFE_CAM_TOL
Note:
Data is described in Chapter 4, "Machine data for SIMODRIVE 611digital"
Overview of MD
for 840D
Overview of MD
for 611 digital
