11.03 2 General Information about Integrated Safety Systems
2.9 System prerequisites
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
2-41
2.9.1 Order numbers
Table 2-6 SINUMERIK 840D
NCU modules Order No.:
NCU 561.4 6FC5356-0BB12-0AE0
NCU 571.4 6FC5357-0BB12-0AE0
NCU 572.4 6FC5357-0BB23-0AE0
NCU 573.4 6FC5357-0BB34-0AE0
NCU 573.5 6FC5357-0BB35-0AE0
Software option SINUMERIK Safety
Integrated
Basic function up to 4 axes/spindles 6FC5250-0AC10-0AA0
Additional function from the 5th axis/spindle
onwards
6FC5250-0AC11-0AA0
Axis/spindle pack for additional 13 axes/
spindles
6FC5250-0AC12-0AA0
NCK I/Os
NCU terminal block 6FC5211-0AA00-0AA0
DMP Compact 16A, 24V, DC 6FC5111-0CA01-0AA0
DMP Compact 16A, 24V, DC, 0.5A 6FC5111-0CA02-0AA2
DMP Compact 8A, 24V, DC, 2A 6FC5111-0CA03-0AA2
Accessories
Cable distributor 6FX2006-1BA02
Software option
for I/O interface via PROFIBUS DP
6FC5252-0AD00-0AA0
Simple I/O module 6FC5411-0AA00-0AA0
Table 2-7 SIMODRIVE 611 digital
Designation Order No.:
High-standard – 2 axis 6SN1118-0DM33-0AA0
High-performance – 1 axis 6SN1118-0DJ23-0AA0
High-performance – 2 axis 6SN1118-0DK23-0AA0
SINUMERIK 840D
SIMODRIVE 611 digital
