3 Safety-Related Functions 11.03

3.8 Safe braking ramp (SBR) (840D from SW 4.2)

3-126 SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03

3.8.1 Overview of the machine data for SBR

Table 3-52 Overview of machine data for 840D

Number Name

36948 $MA_SAFE_STOP_VELO_TOL

32300 $MA_MA_AX_ACCEL

35200 $MA_GEAR_STEP_SPEEDCTRL_ACCEL

35210 $MA_STEP_POSCTRL_ACCEL

35410 $MA_SPIND_OSCILL_ACCEL

Note:

Data is described in Chapter 4, "Machine data for SINUMERIK 840D"

Table 3-53 Overview of machine data for 611 digital

Number Name

1348 $MD_SAFE_STOP_ VELO_TOL

Note:

Data is described in Chapter 4, "Machine data for SIMODRIVE 611digital"

Overview of MD

for 840D

Overview of MD

for 611 digital
