11.03 2 General Information about Integrated Safety Systems
2.10 Customer Support
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
2-43
PROFIsafe ET 200 S
Table 2-9 PROFIsafe ET 200 S
Designation Order No.:
Interface IM 151 HF 6ES7151-1BA00-0AB0
Electronic module 4/8 F - DI 6ES7138-4FA00-0AB0
Electronic module 4/8 F - DO 6ES7138-4FB00-0AB0
Terminal module for F – DI and F – DO
With screw terminal 6ES7193-4CG20-0AA0
With spring-loaded terminal 6ES7193-4CG30-0AA0
With screw terminal 6ES7193-4CF40-0AA0
With spring-loaded terminal 6ES7193-4CF50-0AA0
Power module
Standard 24 V DC 6ES7138-4CA00-0AA0
Standard 24 V DC / 120/230 V AC 6ES7138-4CB10-0AB0
Fail-safe 24 V DC 6ES7138-4CF00-0AB0
Terminal module for fail-safe
power module
With screw terminal 6ES7193-4CK20-0AA0
With spring-loaded terminal 6ES7193-4CK30-0AA0
Terminal module for standard power module
With screw terminal 6ES7193-4CC20-0AA0
With spring-loaded terminal 6ES7193-4CC30-0AA0
With screw terminal 6ES7193-4CD20-0AA0
With spring-loaded terminal 6ES7193-4CD30-0AA0
With screw terminal 6ES7193-4CK20-0AA0
With spring-loaded terminal 6ES7193-4CK30-0AA0
S7 F configuration pack (Distributed Safety) 6ES7833-1FC00-0YX0
Please refer to Catalog ST 70 for further ET 200 S components
2.10 Customer Support
The Centre of Competence Service (CoCS) – Sinumerik Safety Integrated®
provides a range of services for users.
Contact addresses
Hotline: Phone: 0180-5050-222
Fax: 0180-5050-223
E-Mail: ad.support@siemens.com
Inquiry, specifying 840D Safety Integrated
Order per: Phone: +49 (0)9131 98 4386
Fax: +49 (0)9131 98 1359
Table 2-10 Service spectrum (for machine manufacturers and end customers)
Offer Description of services
Concept development The safety functions are adapted to the machine on the basis of the
hazard analysis and the operating philosophy requested by the customer.
This includes e.g.:
• Planned operating modes
• Safety functions when the protective doors are closed
• Safety functions when the protective doors are open
• EMERGENCY STOP concept
• A study of the safety-relevant external signals and elements
Standard configuration Based on the concept development the standard functions
•
Safe standstill (SH), safe operating stop (SBH)
