11.03 3 Safety-Related Functions
3.10 Safe programable logic (SPL) (840D SW 4.4.18)
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
3-139
Crosswise data comparison checks whether the "commissioning phase"
has been completed. If errors are detected in the crosswise data
comparison, a "STOP D/E" is triggered on the NCK/611 digital depending
on this criterion. If the commissioning phase has not been completed,
Alarm 27095 "SPL protection not activated" is displayed once after run-up
and the commissioning status between NCK and PLC cross checked.
As far as the SPL-SGAs are concerned, if an error occurs for a crosswise
data comparison, then a system response is not issued. In this case, the
user must program his own response in the SPL.
Process
Machine
HW
in-
puts/
ouputs
HW
inputs/
out-
puts
NCK
signal
pro-
cessing
NCK
SGE/SGA
signals
Comparator
Data
PLC
signal
pro-
cessing
NC/PLC
interface:
Axis/
spindle DB
Comparator
Data
SPL033.DSF
System
Interface
Interface
NCK signal
processing
PLC signal
processing
NCK
I/Os
PLC
I/Os
Result and data
cross-check
Result and data
cross-check
Drive monitoring channel
NCK monitoring channel
Fig. 3-33 Communications between the NCK-611 digital PLC components
3.10.1 NCK-SPL program
The NCK-SPL program is written as an NC program (synchronous sub-routine)
with synchronized actions.
References: /FBSY/ Description of Functions, Synchronized Actions
The NCK-SPL program has the following features:
The program can be started manually with NC START during
commissioning.
The following applies once the program has been started:
The synchronous actions assigned an ID No. are cyclically executed in
the IPO clock cycles (modal)
The synchronous actions assigned the keyword IDS remain active even
after an operating mode change or NC-STOP/NC RESET
Description
Features

Table of Contents
