11.03 3 Safety-Related Functions
3.9 Safety-related input/output signals (SGE/SGA)
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
3-135
A PLC module that is compatible with the SIMATIC S7 315-2DP is used as the
PLC in the SINUMERIK 840D. Signals are processed according to what has
been programmed in the PLC user program (refer to Chapter 4, "Interface
signals for SINUMERIK 840D").
References: /FB/, P3, "Basic PLC Program"
The machine status is transferred to the monitoring comparators for specific
axes/spindles via the PLC inputs and the PLC user program.
The PLC SGE/SGA interface is mapped using the following axis/spindle-
specific data blocks:
DB 31... (assignment of data block,
refer to Chapter 4 "Interface signals for SINUMERIK 840D")
3.9.3 Overview of the machine data for SGE/SGA
Table 3-55 Overview of machine data for 840D
Number Name
36950 $MA_SAFE_MODE_SWITCH_TIME
36970 $MA_SAFE_SVSS_DISABLE_INPUT
36971 $MA_SAFE_SS_DISABLE_INPUT
36972
$MA_SAFE_VELO_SELECT_INPUT
[n]
36973 $MA_SAFE_POS_SELECT_INPUT
36974
$MA_SAFE_GEAR_SELECT_INPUT
[n]
36975 $MA_SAFE_STOP_REQUEST_INPUT
36976 $MA_SAFE_PULSE_STATUS_INPUT
36977
$MA_SAFE_EXT_STOP_INPUT
[n]
36978
$MA_SAFE_OVR_INPUT
[n]
36979 $MA_SAFE_STOP_REQUEST_EXT_INPUT
36980 $MA_SAFE_SVSS_STATUS_OUTPUT
36981 $MA_SAFE_SS_STATUS_OUTPUT
36982
$MA_SAFE_VELO_STATUS_OUTPUT
[n]
36984 $MA_SAFE_EXT_PULSE_ENAB_OUTPUT
36985 $MA_SAFE_VELO_X_STATUS_OUTPUT
36986 $MA_SAFE_PULSE_ENABLE_OUTPUT
36987 $MA_SAFE_REFP_STATUS_OUTPUT
36988
$MA_SAFE_CAM_PLUS_OUTPUT
[n]
36989
$MA_SAFE_CAM_MINUS_OUTPUT
[n]
36990
$MA_SAFE_ACT_STOP_OUTPUT
[n]
Note:
Data is described in Chapter 4, "Machine data for SINUMERIK 840D"
Processing signals for
840D
PLC SGE/SGA
interface for 840D
Overview of MD
for 840D
