3 Safety-Related Functions 11.03
3.1 Basic mechanisms of SI functions
© Siemens AG 2003 All Rights Reserved
3-76 SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
3.1.6 Overview of the machine data for stop responses
Table 3-8 Overview of machine data for 840D
Number Name
36952 $MA_SAFE_STOP_SWITCH_TIME_C
36953 $MA_SAFE_STOP_SWITCH_TIME_D
36954 $MA_SAFE_STOP_SWITCH_TIME_E
36955 $MA_SAFE_STOP_SWITCH_TIME_F
36956 $MA_SAFE_PULSE_DISABLE_DELAY
36957 $MA_SAFE_PULSE_DIS_CHECK_TIME
36960 $MA_SAFE_STANDSTILL_VELO_TOL
36961 $MA_SAFE_VELO_STOP_MODE
36962 $MA_SAFE_POS_STOP_MODE
36963 $MA_SAFE_VELO_STOP_REACTION
Note:
Data is described in Chapter 4, "Machine data for SINUMERIK 840D"
Table 3-9 Overview of machine data for 611 digital
Number Name
1352 $MD_SAFE_STOP_SWITCH_TIME_C
1353 $MD_SAFE_STOP_SWITCH_TIME_D
1354 $MD_SAFE_STOP_SWITCH_TIME_E
1355 $MD_SAFE_STOP_SWITCH_TIME_F
1356 $MD_SAFE_PULSE_DISABLE_DELAY
1357 $MD_SAFE_PULSE_DIS_CHECK_TIME
1360 $MD_SAFE_STANDSTILL_VELO_TOL
1361 $MD_SAFE_VELO_STOP_MODE
1362 $MD_SAFE_POS_STOP_MODE
1363 $MD_SAFE_VELO_STOP_REACTION
1395 $MD_SAFE_STOP_F_DIAGNOSIS
Note:
Data is described in Chapter 4, "Machine data for SIMODRIVE 611digital"
Overview of MD
for 840D
Overview of MD
for 611 digital
