3 Safety-Related Functions 11.03
3.11 Encoder mounting arrangements
© Siemens AG 2003 All Rights Reserved
3-174 SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
For 1-encoder systems, it is advisable to replace the entire motor in the case of
a defect in the motor measuring system (indirect measuring system).
!
Warning
After the measuring system has been replaced - regardless of whether it is a
direct or indirect system - the relevant axis must be re-calibrated.
The user can suppress the automatic, internal actual value check by resetting
the "User agreement" and thus request re-calibration of the axis with user
agreement.
3.11.3 Overview of the data for mounting encoders
Table 3-65 Overview of machine data for 840D
Number Name
36910 $MA_SAFE_ENC_SEGMENT_NR
36911 $MA_SAFE_ENC_MODULE_NR
36912 $MA_SAFE_ENC_INPUT_NR
36915 $MA_SAFE_ENC_TYPE
36916 $MA_SAFE_ENC_IS_LINEAR
36917 $MA_SAFE_ENC_GRID_POINT_DIST
36918 $MA_SAFE_ENC_RESOL
36920 $MA_SAFE_ENC_GEAR_PITCH
36921 $MA_SAFE_ENC_GEAR_DENOM[n]
36922 $MA_SAFE_ENC_GEAR_NUMERA[n]
36925 $MA_SAFE_ENC_POLARITY
Note:
Data is described in Chapter 4, "Machine data for SINUMERIK 840D"
Table 3-66 Overview of machine data for 611 digital
Number Name
1316 $MD_SAFE_ENC_CONFIG
1317 $MD_SAFE_ENC_GRID_POINT_DIST
1318 $MD_SAFE_ENC_RESOL
1320 $MD_SAFE_ENC_GEAR_PITCH
1321 $MD_SAFE_ENC_GEAR_DENOM[n]
1322 $MD_SAFE_ENC_GEAR_NUMERA[n]
Note:
Data is described in Chapter 4, "Machine data for SIMODRIVE 611digital"
Replacing encoders
Overview of MD
for 840D
Overview of MD
for 611 digital
