2 General Information about Integrated Safety Systems 11.03
2.9 System prerequisites
© Siemens AG 2003 All Rights Reserved
2-42 SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
PLC
(SIMATIC S7-300)
Table 2-8 PLC (SIMATIC S7-300
Interfaces Order No.:
Interface IM 360 6ES7360-3AA01-0AA0
Interface IM 361 6ES7361-3CA01-0AA0
Interface IM 365 6ES7365-0BA01-0AA0
Interface IM 365 (extended temperature range) 6ES7365-0BA81-0AA0
Digital input modules SM 321
16 inputs / 24 V DC 6ES7321-1BH02-0AA0
16 inputs / 24 V DC (extended temperature
range)
6ES7321-1BH82-0AA0
16 inputs, 24 V, DC m - reading 6ES7321-1BH50-0AA0
32 inputs / 24 V DC 6ES7321-1BL00-0AA0
32 inputs / 24 V DC (extended temperature
range)
6ES7321-1BL80-0AA0
16 inputs / 24 V DC, diagnostics capable 6ES7321-7BH00-0AA0
16 inputs / 24 V DC, diagnostics capable
(extended temperature range)
6ES7321-7BH80-0AA0
16 inputs, 120 V, AC 6ES7321-1EH01-0AA0
32 inputs, 120 V, AC 6ES7321-1EL00-0AA0
8 inputs, 120/230 V, AC 6ES7321-1FF01-0AA0
Digital output modules SM322
16 outputs, 24 V, DC, 0.5 A 6ES7322-1BH01-0AA0
16 outputs / 24 V DC 0.5 A (extended
temperature range)
6ES7322-1BH81-0AA0
32 outputs, 24 V, DC, 0.5 A 6ES7322-1BL00-0AA0
8 outputs, 24 V, DC, 0.5 A
diagnostics capable
6ES7322-8BF00-0AA0
16 outputs, 120 V, AC, 0.5 A 6ES7322-1EH01-0AA0
32 outputs, 120 V, AC, 1 A 6ES7322-1EL00-0AA0
8 outputs, 24 V, DC, 2 A 6ES7322-1BF01-0AA0
8 outputs, 120/230 V, AC, 1 A 6ES7322-1FF01-0AA0
8 outputs / 120/230 V AC 1 A
(extended temperature range)
6ES7322-1FF81-0AA0
8 outputs, relay contacts 2 A 6ES7322-1HF01-0AA0
8 outputs, relay contacts 5 A 6ES7322-1HF10-0AA0
8 outputs, relay contacts 5 A
(extended temperature range)
6ES7322-1HF80-0AA0
16 outputs, relay contacts 2 A 6ES7322-1HH00-0AA0
Digital input/output modules SN323
8 inputs / 8 outputs 6ES7323-1BH01-0AA0
8 inputs / 8 outputs
(extended temperature range)
6ES7323-1BH81-0AA0
16 inputs / 16 outputs 6ES7323-1BL00-0AA0
Please refer to Catalog ST 70 for further SIMATIC components

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
