11.03 4 Data Descriptions
4.4 System variable
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
4-265
System variables
from SW 6
System variables Meaning Value range Data type Possible access for
Part
program
Synchr.
action
l s l s
Actual position
$A_XFAULTSI
(from SW 6.4.15)
0: In the crosswise data
comparison between NCK
and 611D of any axis, an
actual-value error has
been detected
1: In the crosswise data
comparison between NCK
and 611D of any axis, an
error was detected and
the delay time until
STOP B is initiated in this
axis is running or has
already expired.
[0,3] INT x x
$VA_XFAULTSI[axis]
(from SW 6.4.15)
0: For a crosswise data
comparison of this axis
between NCK and 611D,
an actual value error has
been detected
1: In the crosswise data
comparison between NCK
and 611D of any axis, an
error was detected and
the delay time until
STOP B is initiated in this
axis is running or has
already expired.
[0,3] INT x x
$VA_STOPSI
(from SW 6.4.15)
Actual Safety Integrated stop of
relevant axis
–1: No stop
0: Stop A
1: Stop B
2: Stop C
3: Stop D
4: Stop E
5: Stop F
10: Test stop
11: Test, external pulse
cancellation
[-1,11] INT x x
$VA_STOPESI
(from SW 6.4.15)
Actual Safety Integrated Stop E for
any axis
0: No stop
Otherwise: For one of the axes,
a Stop E is present
[0,MAX_INT] INT x x
$A_PLCSIIN
(from SW 6.3.30)
Single-channel direct
communication between NCK and
PLC-SPL. Signals can be written by
the PLC and read by the NCK.
[FALSE,
TRUE]
BOOL x x
$A_PLCSIOUT
(from SW 6.3.30)
Single-channel direct
communication between NCK and
PLC-SPL. Signals can be read by
the PLC and written by the NCK.
[FALSE,
TRUE]
BOOL x x
