Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-100 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Signal I/O Type Value range Remarks
MCP1Out
MCP2Out
I Pointer Q0.0 to Q120.0 or
M0.0 to M248.0 or
DBn.DBX0.0 to
DBXm.0
Start address for
output signals of relevant
machine control panel
1)
MCP1StatSend
MCP2StatSend
I Pointer Q0.0 to Q124.0,
M0.0 to M252.0 or
DBn.DBX0.0
to DBXm.0
Start address for status double
word for data transmission from
machine control panel:
DW#16#00080000:
Timeout, otherwise 0
1)
MCP1StatRec
MCP2StatRec
I Pointer Q0.0 to Q124.0,
M0.0 to M252.0 or
DBn.DBX0.0
to DBXm.0
Start address for status double
word for data reception by machine
control panel: DW#16#00040000:
Timeout, otherwise 0
1)
MCP1BusAdr
MCP2BusAdr
I Int 1... 15 Bus address of machine control
panel
MCP1Timeout
MCP2Timeout
I S5time Recommendation:
700 ms
Cyclic sign-of-life monitoring for
machine control panel
MCP1Cycl
MCP2Cycl
I S5time Recommendation:
200 ms
Time reference for cyclic updating
of signals to machine control panel
MCPMPI I Bool 1: All machine control panels
connected to the MPI bus
(without GD parameterization)
MCP1Stop
MCP2Stop
I Bool 0: Start transfer of machine control
panel signals
1: Stop transfer of machine control
panel signals
MCP1NotSend
MCP2NotSend
I Bool 0: Send and receive operation
activated
1: Receive machine control panel
signals only
HHU I Int Handheld unit interface
0: No HHU
1: HHU on MPI with SDB 210
configuration
BHGIn I Pointer I0.0 to I124.0,
M0.0 to M252.0
or DBn.DBX0.0
to DBXm.0
Start address
PLC receive data
from HHU
2)
BHGOut I Pointer Q0.0 to Q124.0,
M0.0 to M252.0
or
DBn.DBX0.0
to DBXm.0
Start address
PLC transmit data
to HHU
2)
