Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-101
Signal I/O Type Value range Remarks
BHGStatSend I Pointer Q0.0 to Q124.0,
M0.0 to M252.0
or DBn.DBX0.0
to DBXm.0
Start address for the
status double word for sending data
to the HHU:
DW#16#08000000: Timeout,
otherwise 0
2)
BHGStatRec I Pointer Q0.0 to Q124.0,
M0.0 to M252.0
or
DBn.DBX0.0
to DBXm.0
Start address for the
status double word for receiving
data from HHU:
DW#16#00040000: Timeout,
otherwise 0
2)
BHGInLen I BYTE HHU default:
B#16#6 (6 bytes)
Quantity of data received from
handheld unit
BHGOutLen I Byte HHU default:
B#16#14 (10 bytes)
Quantity of data transmitted to
handheld unit
BHGTimeout I S5time Recommendation:
700 ms
Cyclic sign-of-life
monitoring for handheld unit
BHGCycl I S5time Recommendation:
100 ms
Time reference for cyclic updating
of signals to handheld unit
BHGRecGDNo I Int HHU default: 1 Receive GD circle no.
BHGRecGBZNo I Int HHU default: 2 Receive GI no.
BHGRecObjNo I Int HHU default: 1 Object number for receive GI
BHGSendGDNo I Int HHU default: 2 Transmit GD circle no.
BHGSendGBZNo I Int HHU default: 1 Transmit GI no.
BHGSendObjNo I Int HHU default: 1 Object number for transmit GI
BHGMPI I Bool 1: Handheld unit coupled to MPI
(without SDB 210 config.)
Parameter HHU must be set to 2.
BHGStop I Bool 0: Start transfer of HHU signals
1: Stop transfer of HHU signals
BHGNotSend I Bool 0: Send and receive operation
activated
1: Receive HHU signals only
NCCyclTimeout I S5time Recommendation:
200 ms
Cyclic sign-of-life
monitoring NCK
NCRunupTimeout I S5time Recommendation:
50 s
Powerup monitoring NCK
ListMDecGrp I INT 0...16
NCKomm I Bool PLC NC communications services
(FB 2/3/4/5/7:
Put/Get/PI_SERV/GETGUD)
1: active
