2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-102 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Signal I/O Type Value range Remarks
MMCToIF I Bool Transmission of MMC signals
to interface (modes,
program control, etc.)
true: active
HWheelMMC I Bool True: Handwheel selection via
MMC
False: Handwheel selection using
user prog.
MsgUser I Int 0...25 Number of user areas for messages
(DB 2)
UserIR I Bool Local data expansion OB40
required for processing of signals
from user
IRAuxfuT I Bool Evaluate T function in OB40
IRAuxfuH I Bool Evaluate H function in OB40
IRAuxfuE I Bool Evaluate DL function in OB40
UserVersion I Pointer Pointer to string variable.
The associated string variable is
indicated in the version display
(max. 54 characters).
MaxBAG Q INT 1..10 Number of mode groups
MaxChan Q INT 1..10 Number of channels
MaxAxis Q INT 1..31 Number of axes
ActivChan Q ARRAY
[1..10] OF
BOOL
Bit string for active channels
ActivAxis Q ARRAY
[1.0.31] OF
BOOL
Bit string for active axes
UDInt Q Int Quantity of integer machine data in
DB20
UDHex Q Int Quantity of hexadecimal machine
data in DB20
UDReal Q Int Quantity of real machine data in
DB20
1)
To ensure BP monitoring of the MCP(s), the addresses must be specified as set in SDB 210 on the
810D. The start address is set via SDB 210 on the 810D. In the supplied SDB 210, the start address
is specified as IB 0 for input signals and QB 0 for output signals. If a different start address is
required, this must be specified using the STEP 7 Communication Configuration package.
2)
To ensure BP monitoring of the HHU(s), the addresses must be specified as set in SDB 210 on the
810D.
