Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-123
Overview of PI services
The following section provides an overview of the PI services that can be started from the
PLC. The meaning and application of the general FB 4 input variables (Unit, Addr ..., WVar
...) depend on the individual PI service concerned.
PI service Function Available in 840D/810D
SELECT Select program for processing for one channel x
ASUB Assign interrupt x
FINDBL Activate block search x
SETUFR Activate user frames x
CONFIG Reconfiguration of
tagged machine data
x
CANCEL Execute cancel x
DELETO Delete tool x
CREATO Generate tool x
CREACE Create cutting edge x
TMCRTO Create tool x
TMFDPL Empty location search for loading x
TMMVTL Prepare magazine location for loading, unload tool x
TMPOSM Position magazine location or tool x
LOGIN Activate password x x
LOGOUT Reset password x x
MMCSEM Semaphores for various PI services x
CRCEDN Create new cutting edge x
DELECE Delete a cutting edge x
TMFPBP Empty location search x
TSEARC Complex search using search screen forms x
TMPCIT Set increment value for workpiece counter x
DIGION Digitizing on x
DIGIOF Digitizing off x
NCRES Initiate NC Reset x
TMRASS Reset active status x
TRESMO Reset monitoring values x
ACTDEF Activate a definition (GUD or macro) x
x: PI service is available
