Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-124 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
PI service: SELECT
Select a program for execution for a channel.
Function:
A program stored on the NCK is selected for processing for one channel. This is possible
only if the file may be executed. The path name and program name must be entered as
described in the Programming Guide (Chapter "File and Program Management", Section
"Program Memory"). Please also refer to example of FB 4 for notation of path and program
names.
Possible block types
Block types
Workpiece directory WPD
Main program MPF
Subroutine SPF
Cycles CYC
Asynchronous subprograms ASP
Binary files BIN
Parameterization
Signal Type Value range Meaning
PIService ANY PI.SELECT Program selection
Unit INT 1 to 10 Channel
Addr1 STRING Path name
Addr2 STRING Program name
PI service: ASUB
Assign interrupt
Function:
A program stored on the NCK is assigned an interrupt signal for a channel. This is possible
only if the file may be executed. The path name and program name must be entered as
described in the Programming Guide (Chapter "File and Program Management", Section
"Program Memory"). Please also refer to example of FB 4 for notation of path and program
names.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.ASUP Assign interrupt
Unit INT 1 to 10 Channel
WVar1 WORD 1 to 8 Interrupt number
