Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-128 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CREACE Create cutting edge
Unit INT 1, 2 TOA
WVar1 INT T number
PI service: TMCRTO
Create tool
Function:
Creation of a tool with specification of an identifier, a duplo number and a T number
(optional). The tool is entered as existing in the tool directory area (TV). The first cutting
edge "D1" (with zero contents) is created for tool offsets in the TO block. "D1" (with zero
contents) is also set up for the monitoring data in the TS block, and simultaneously with zero
contents for the OEM cutting edge data in the TUE block - if one is present. The TD block
contains the identifier, duplo number and number of cutting edges (=1) for the T number that
is entered optionally or allocated by the NCK. If a TU block exists, it will contain the data set
for the tool.
After execution of the PI, the T number of the tool created is available in the TV block under
TnumWZV.
Note
Before and after this PI service, the MMCSEM PI service must be called up with the
associated parameter WVar1 for this PI service. See PI service MMCSEM for more
information.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.TMCRTO Create tool
Unit INT 1, 2 TOA
WVar1 INT T number
WVar2 INT Duplo number
Addr1 STRING max. 32 characters Tool identifier
T number > 0 means a T number must be specified
T number = -1 means that the NCK should allocate a T number
The example shows T number = -1 ⇒ T number assigned by NCK
