Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-127
PI service: DELETO
Delete tool
Function:
Deletes the tool assigned to the transferred T number with all cutting edges (in TO, in some
cases TU, TUE and TG (type 400), TD and TS blocks).
Parameterization
Signal Type Value range Meaning
PIService ANY PI.DELETO Delete tool
Unit INT 1, 2 TOA
WVar1 INT T number
PI service: CREATO
Create tool
Function:
Creation of a tool with specification of a T number. The tool is entered as existing in the tool
directory area (TV). The first "cutting edge" D1 (with zero contents) is created for tool offsets
in the TO block. D1 (with zero contents) is also created for the OEM "cutting edge" data in
the TUE block - if one is present. If a TU block exists, it will contain the data set for the tool.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CREATO Create tool
Unit INT 1, 2 TOA
WVar1 INT T number
PI service: CREACE
Create cutting edge
Function:
Creation of the cutting edge with the next higher/next unassigned D number for the tool with
the transferred T number in TO, TS (if present). The cutting edge for the OEM cutting edge
data is set up simultaneously in the TUE block - if one is present.
