Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-221
Operating modes and machine functions
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
AUTOMATIC DB11, ... DBX0.0
MDA DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. (SW 5 and higher) DB11.DBB2, Bits 0 to 5
SW 4 and lower
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
INC 1 ... 10 000, INC Var. DB21, ... DBB13, Bit 0 to 5
INC 1 ... 10 000, INC Var. DB21, ... DBB17, Bit 0 to 5
INC 1 ... 10 000, INC Var. DB21, ... DBB21, Bit 0 to 5
Source:
MCP button
Destination:
Interface DB (all axis DBs)
INC 1 ... 10 000, INC Var.
(up to SW 4)
DB31, ... DBB5, Bit 0 to 5
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The associated interface bits are deleted
for axes, which are not selected.
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
