Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-222 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Source:
MCP button
Destination:
Interface DB (all axis DBs)
Direction key + DB31, ... DBX4.7
Direction key - DB31, ... DBX4.6
Rapid traverse override DB31, ... DBX4.5
Override
Source:
MCP switch
Destination:
Interface DB (Parameter ChanNo)
Feedrate override DB21, ... DBB4
Source:
MCP switch
Destination:
Interface DB (all axis DBs)
Feedrate override DB31, ... DBB0 (selected axis number) The feed override
of the 1st MCP applies to all axes.
Spindle override DB31, ... DBB19 (parameter SpindleIFNo)
Channel signals
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
NC Start DB21, ... DBX7.1
NC stop DB21, ... DBX7.3
Reset DB21, ... DBX7.7
Single block DB21, ... DBX0.4
Feedrate, spindle signals
Source:
MCP button
Destination:
FC output parameters
Feed stop
Feed enable
Parameter: "FeedHold" latched, LEDs are
driven
Spindle stop
Spindle enable
Parameter: "SpindleHold" latched, LEDs
are driven
