Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-111
Note
The SETINT instruction is also used to make the assignment.
The ASUB PI service may only be executed when the channel to be activated is in Reset.
References:
/PA/ Programming Guide
PI service: CANCEL
Execute cancel
Function:
The CANCEL command activates the Cancel function (in the same way as the key on the
HMI).
Parameter assignment
Signal Type Value range Meaning
PIService ANY PI.CANCEL Cancel
PI service: CONFIG
Reconfiguration
Function:
The reconfiguration command activates machine data, which have been entered sequentially
by the operator or the PLC, almost in parallel.
The command can only be activated when the control is in Reset or the program is
interrupted (NC stop at block limit). An FB 4 error checkback signal is output if these
conditions are not fulfilled (state = 3).
Parameter assignment
Signal Type Value range Meaning
PIService ANY PI.CONFIG Reconfiguration
Unit INT 1
WVar1 INT 1 Classification
