Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
2-112 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
PI service: DIGION
Digitizing on
Function:
Select digitizing in the specified channel.
Parameter assignment
Signal Type Value range Meaning
PIService ANY PI.DIGION Digitizing on
Unit INT 1 to 10 Channel
PI service: DIGIOF
Function:
Deactivating digitizing in the specified channel
Parameterization:
Signal Type Value range Meaning
PIService ANY PI.DIGIOF Digitizing off
Unit INT 1 to 10 Channel
PI service: FINDBL
Activate block search
Function:
A channel is switched to block search mode and the appropriate acknowledgment then
transmitted. The block search is then executed immediately by the NCK. The search pointer
must already be in the NCK at this point in time. The search can be interrupted at any time
by an NC RESET. Once the search is successfully completed, the normal processing mode
is reactivated automatically. NC Start then takes effect from the located search target. The
operator is responsible for providing a collision-free approach path.
