Detailed Description
2.16 Feeds (V1)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-137
DB21, ...
DBB5
Rapid traverse override
7DEOH*UD\FRGLQJIRUUDSLGWUDYHUVHRYHUULGH
6ZLWFK
SRVLWLRQ
&RGH
5DSLGWUDYHUVH
RYHUULGHIDFWRU
VWDQGDUGYDOXHV
The factors listed in the table for the rapid traverse override are stored in the machine
data:
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n].
The table contains the default settings.
The number of possible switch settings for standard machine control panels is described in the
Configuring Guides for 840D/810D.
Corresponding to .... DB21, ... DBX6.6 (rapid traverse override active)
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n] (evaluation of the path feed rate override switch)
MD12100 $MN_OVR_FACTOR_LIMIT_BIN (limit for binary coded override switch)
