1.2 Overview of auxiliary functions
Auxiliary Function Output to PLC (H2)
1-6 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Remarks
• Identification of tools either by means of tool number or location number.
References
/FBW/ Tool Management
/FB/ Description of Functions Basic Machine; Tool Compensation (W1)
• When T0 is selected, the current tool is removed from the tool holder but not replaced by
a new tool (default setting).
• T-function-specific machine data:
– MD22220 $MC_AUXFU_T_SYNC_TYPE
D functions
D (tool offset)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
- - - - - - 0 - 9 INT Selection of the tool
offset
1
Remarks:
Deselection of the tool offset with D0; the default is D1
Application
Selection of the tool offset.
Remarks
• Initial setting: D1
• The default tool cutting edge after tool change can be parameterized via:
MD20270 $MC_CUTTING_EDGE_DEFAULT
• Deselection of the tool offset: D0
• D-function-specific machine data:
– MD22250 $MC_AUXFU_D_SYNC_TYPE
