Detailed Description
2.9 Program control
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-133
Path compilation
An external subroutine is called by means of parts program command EXTCALL.
From
• - The subroutine name programmed in EXTCALL and
- Setting data SD42700 $SC_EXT_PROG_PATH
results the program path for the external subroutine call through a character string
comprising
• The contents of SD42700 $SC_EXT_PROG_PATH
(e.g., /_N_WKS_DIR/_N_WKST1_WPD)
• The character "/" as a separator (if a path was specified with
SD42700 $SC_EXT_PROG_PATH)
• The subroutine path or identifier programmed in EXTCALL.
SD42700 $SC_EXT_PROG_PATH is preassigned with a blank. If an external subroutine is
called without an absolute path name, HMI Advanced runs through the same search path as
applied when a subroutine is called from the NCK memory.
current directory / subroutine identifier
current directory / subroutine identifier_SPF
current directory / subroutine identifier_MPF
/_N_SPF_DIR / subroutine identifier_SPF
/_N_CUS_DIR / subroutine identifier_SPF
/_N_CMA_DIR / subroutine identifier_SPF
/_N_CST_DIR / subroutine identifier_SPF
"current directory": stands for the directory in which the main
program has been selected
"subroutine identifier" stands for the subroutine identifier programmed
in EXTCALL
Example
The program to be reloaded is stored on the local hard disk of HMI Advanced:
• SD42700 $SC_EXT_PROG_PATH = "_N_WKS_DIR/_N_WST1"
Main program_N_MAIN_MPF
(stored in NC memory and is selected for execution)
:N010 PROC MAIN
N020 ....
N030
EXTCALL "ROUGHING"
N040 .....
N050 M30
