Detailed Description
2.9 Program control
Mode Group, Channel, Program Operation, Reset Response (K1)
2-134 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Subroutine_N_ROUGHING_SPF
(stored in HMI memory under workpieces->WP1)
N010 PROC ROUGHING
N020 G1 F1000
N030 X= ... Y= ... Z= ...
N040 .....
....
....
N999999 M17
Windows path name
Program to be reloaded is stored on network drive or ATA card
• EXTCALL Windows path name
Call for network drive (HMI Embedded or HMI Advanced) e.g.,
EXTCALL \\R4711\Workpieces\Contour.1.spf
Call for ATA card (HMI Embedded) e.g.,
EXTCALL C:\Workpieces\Contour.2.spf
Note
An absolute path must always be specified in HMI Embedded.
For further explanations about operation under HMI Embedded/Advanced, refer to:
References:
/BEM/, HMI Embedded, "Execution from network", "Execution from ATA card" and
"EXTCALL"
/BAD/, HMI Advanced, access to external network drive/computer
Power On, RESET
External subroutine calls are aborted and the respective FIFO (reload) buffer erased by a
RESET or POWER ON.
A program selected for "Process from external" remains selected for "Process from external"
after a Reset. A POWER ON deletes the selection. Default program MPF0 is selected
instead.
