Functions
116
7SS52 V4 Manual
C53000-G1176-C182-3
5.3.3 Settings for the Central Unit
5.3.4 List of Information from the Central Unit
Addr. Setting Title Setting Options Default Setting Comments
118 I> BF 0.10 .. 2.00 I / In 0.50 I / In Current threshold for BF
119 I> BF-EF 0.05 .. 2.00 I / In 0.25 I / In Current threshold for BF - EF
6201 STAB FAC:BF 0.00 .. 0.80 0.50 Stabilizing factor BF protection
6202A Is< BF.EF 0.00 .. 25.00 I/In 5.00 I/In Stabilizing current threshold - BF
- EF
FNo. Alarm Comments
10478 >EF charact. >Earth fault characteristic active
