PC Port of the Bay Unit
181
7SS52 V4 Manual
C53000-G1176-C182-3
5.12.3 Settings of the Bay Unit
Addr. Parameters Setting Options Default Settings Comments
7208 FUNCT. TYPE 1 .. 254 160 Function type in accordance with
VDEW/ZVEI
7211 PC INTERF. DIGSI V3
ASCII
DIGSI V3 Data format
7215 PC BAUDRATE 1200 Baud
2400 Baud
4800 Baud
9600 Baud
19200 Baud
9600 Baud Transmission rate for PC poirt
7216 PC PARITY DIGSI V3
No parity,2 stopbits
No parity,1 stopbit
DIGSI V3 Parity of transmission telegrams
7233 SYS SUBV.T 1.. 600 s ; +* 120 s Supervision time for system in-
terface
