5.17.3 Settings of the Bay Unit
Addr. Parameters Setting Options Default Settings Comments
2801 T-Annunc.1 0.00..10.00 s 0.00 s Delay time for 1st user defined
annunciation
2802 T-Annunc.2 0.00..10.00 s 0.00 s Delay time for 2nd user defined
annunciation
2803 T-Annunc.3 0.00..10.00 s 0.00 s Delay time for 3rd user defined
annunciation
2804 T-Annunc.4 0.00..10.00 s 0.00 s Delay time for 4th user defined
annunciation
2811 ANNUN1byCU NO
YES
NO Processing of annunciation 1 by
central unit
2812 ANNUN2byCU NO
YES
NO Processing of annunciation 2 by
central unit
2813 ANNUN3byCU NO
YES
NO Processing of annunciation 3by
central unit
2814 ANNUN4byCU NO
YES
NO Processing of annunciation 4 by
central unit
2821 ANN1Fct.No 0..9999 0 Binary input annunciation
(Fct.no) by annunc.1
2822 ANN2Fct.No 0..9999 0 Binary input annunciation
(Fct.no) by annunc.2
2823 ANN3Fct.No 0..9999 0 Binary input annunciation
(Fct.no) by annunc.3
2824 ANN4Fct.No 0..9999 0 Binary input annunciation
(Fct.no) by annunc.4
2831 ANN1Inp.No 0..9999 0 Input annunciation (no.) for user
logic1
2832 ANN2Inp.No 0..9999 0 Input annunciation (no.) for user
logic2
2833 ANN3Inp.No 0..9999 0 Input annunciation (no.) for user
logic3
2834 ANN4Inp.No 0..9999 0 Input annunciation (no.) for user
logic4
