5.5.4 List of Information from the Central Unit
FNo. Alarm Comments
10410 Id-sup CZ M Diff-current superv. CZ (group alarm)
10411 Id-sup CZ L1 Diff-current supervision Check Zone L1
10412 Id-sup CZ L2 Diff-current supervision Check Zone L2
10413 Id-sup CZ L3 Diff-current supervision Check Zone L3
10415 Id-sup BZ M Diff-current superv. BZ (group alarm)
10416 Id-sup BZ L1 M Diff-current superv. BZ L1 (group alarm)
10417 Id-sup BZ L2 M Diff-current superv. BZ L2 (group alarm)
10418 Id-sup BZ L3 M Diff-current superv. BZ L3 (group alarm)
10420 15V-superv CU 15V supply supervision central unit
10421 24V-superv CU 24V supply supervision central unit
10422 Batt. superv CU Battery supervision central unit
10423 Meas sup BU M Measured value superv. BU (group alarm)
10424 Supply sup BU M Supply voltage superv. BU (group alarm)
10425 Isol flt alarm Isolator fault alarm
10426 Bay DC fail M Failure of isolator aux. voltage (g. a.)
10427 Isol flt run M Isolator fault: run time (group alarm)
10428 Isol flt pos M Isolator position faulty (group alarm)
10429 Flt autotest M Failure in auto testing (group alarm)
10444 Block ZeroCross Blocking by supervision zero crossing
10470 IsoProhib/fault Isolator oper. prohibitted (isol.fault)
176.1091 BFBIErr $00 L1 Timing error BF input $00 L1
176.1092 BFBIErr $00 L2 Timing error BF input $00 L2
176.1093 BFBIErr $00 L3 Timing error BF input $00 L3
176.1094 BFBIErr $00 3P Timing error BF input $00 3pole
176.1101 BFRlErr $00 1P Timing error BF release $00 1pole
176.1102 BFRlErr $00 3P Timing error BF release $00 3pole
176.1110 $01 $02 $01 Isolator $02
176.1112 FltR $01 $02 Fault: run time $01 isolator $02
176.1113 FltP $01 $02 Fault: dist. pos. $01 isol. $02
176.1117 FltR $01 $02 Fault: run time $01 isol. $02
176.1118 FltP $01 $02 Fault: dist. pos. $01 isol. $02
176.1122 FltR $01 $02 Fault: run time $01 isol. $02
176.1123 FltP $01 $02 Fault: dist. pos. $01 isol. $02
