Parameter Listing - Central Unit
365
7SS52 V4 Manual
C53000-G1176-C182-3
A.7 Parameter Listing - Central Unit
In the running text of the manual, "XX" is usually used as variable for the first digit
(number of the bay unit) of the parameters 106A to 156A (XX12 instead of 112).
Addr. Setting Title Function Setting Options Default Setting Comments
106A Combi-Coupler BU@ YES
NO
NO Combi-Coupler
112 Bay status BU@ out of service
in service
maintenance
in service Bay status
113 I>TRIP BU@ 0.00 .. 25.00 I/In 0.00 I/In Current threshold for TRIP release
114 BF BI MODE BU@ 1-ch w/o sup
1-ch w sup
2-ch w/o sup
2-ch w sup
1-ch w sup Binary input mode / supervision BF
115 BF OP MODE BU@ non existent
external
BZ unbalance
trip rep/unbal
I>query
trip rep/I>quer
BZ unbalance Operation mode BF
116 BF I< BU@ ON
OFF
OFF Low-current mode BF
117 TRIP REP. MODE BU@ 1pole
3pole
1pole TRIP repeat mode
118 I> BF BU@ 0.10 .. 2.00 I/In 0.50 I/In Current threshold for BF
119 I> BF-EF BU@ 0.05 .. 2.00 I/In 0.25 I/In Current threshold for BF - EF
120 T-BF-1P BU@ 0.05 .. 10.00 sec 0.25 sec Time delay for BF with 1-pole faults
121 T-BF-mP BU@ 0.05 .. 10.00 sec 0.25 sec Time delay for BF with multi-pole faults
122 T-BF I< BU@ 0.05 .. 10.00 sec 0.25 sec Time delay for BF low current mode
123A T-BF IMP BU@ 0.05 .. 10.00 sec 0.50 sec Time delay for BF pulse mode
124 T-BF CB fault BU@ 0.00 .. 10.00 sec 0.10 sec Time delay BF after CB fault
125 T-TRIP repeat BU@ 0.00 .. 10.00 sec 0.12 sec Time delay for TRIP repeat
126 T-CB open BU@ 0.00 .. 10.00 sec 0.00 sec Time delay for CB open
127 T-BF rel sup BU@ 0.02 .. 15.00 sec 15.00 sec Supervision bin. input BF-release
128 T-BF 2chan BU@ 0.06 .. 1.00 sec 0.06 sec Supervision time BF start / release
129 End Fault Prot BU@ ON
OFF
OFF End fault protection
151A Maint. Iso1 BU@ YES
NO
YES Maintenance for Isolator 1
152A Maint. Iso2 BU@ YES
NO
YES Maintenance for Isolator 2
153A Maint. Iso3 BU@ YES
NO
YES Maintenance for Isolator 3
154A Maint. Iso4 BU@ YES
NO
YES Maintenance for Isolator 4
155A Maint. Iso5 BU@ YES
NO
YES Maintenance for Isolator 5
156A Maint. CB BU@ YES
NO
YES Maintenance for CB
5104 FREQUENCY P.System Data 1 50 Hz
60 Hz
50 Hz Nominal frequency
5108A Test mode SK Protec. general OFF
ON
OFF Test mode for module SK
5111A Language BU Protec. general German
English
French
Spanish
Italian
Russian
English Language of bay units
5112A OutEn BU-TEST Protec. general NO
YES
NO Output enable bay unit under test
