Appendix
366
7SS52 V4 Manual
C53000-G1176-C182-3
5299A TO IV-Bit T103 Device 0 .. 1500 min 1380 min Timeout IV-Bit T103
5401 PROT TR BUS Protec. general YES
NO
YES Selective protection for transfer busbar
6101 STAB FAC:BZ BB Protection 0.10 .. 0.80 0.65 Stabilizing factor - BZ
6102 Id> BZ BB Protection 0.20 .. 4.00 I/Ino 1.00 I/Ino Diff-current threshold - BZ
6103 STAB FAC:CZ BB Protection 0.00 .. 0.80 0.50 Stabilizing factor - CZ
6104 Id> CZ BB Protection 0.20 .. 4.00 I/Ino 1.00 I/Ino Diff-current threshold - CZ
6106 Tmin TRIP Protec. general 0.01 .. 32.00 sec 0.15 sec Minimum duration of TRIP command
6108A Is< BZ.EF BB Protection 0.00 .. 25.00 I/Ino 5.00 I/Ino Stabilizing current threshold - BZ.EF
6109A Id> BZ.EF BB Protection 0.05 .. 4.00 I/Ino 0.25 I/Ino Diff-current threshold - BZ.EF
6110A Is< CZ.EF BB Protection 0.00 .. 25.00 I/Ino 4.50 I/Ino Stabilizing current threshold - CZ.EF
6111A Id> CZ.EF BB Protection 0.05 .. 4.00 I/Ino 0.25 I/Ino Diff-current threshold - CZ.EF
6201 STAB FAC:BF BF-Protection 0.00 .. 0.80 0.50 Stabilizing factor BF protection
6202A Is< BF.EF BF-Protection 0.00 .. 25.00 I/In 5.00 I/In Stabilizing current threshold - BF.EF
6301 ISOL TIME Monitoring 1.00 .. 180.00 sec 7.00 sec Limit value isolator time
6302 ISOL Malfunct Monitoring alarm only
blocking
block./release
block./acknow.
alarm only Reaction on isolator malfunction
6303 ISOL DC FAIL Monitoring OLD
ON
OLD Treatment isolator status on DC fail
6304 ISOL ST 1/1 Monitoring OLD
ON
OLD Treatment isolator status not plausible
6305 BLOCKING MODE Monitoring zone/phase
protection
zone/phase Blocking mode on failure
6306 DIFF SUPERV Monitoring ON
OFF
ON Differential current supervision
6307 T-Idiff SUPERV Monitoring 1.00 .. 10.00 sec 2.00 sec Time delay for diff-current supervision
6308 Id> SUPERV BZ Monitoring 0.05 .. 0.80 I/Ino 0.10 I/Ino Limit value diff-current supervision -BZ
6309 Id> SUPERV CZ Monitoring 0.05 .. 0.80 I/Ino 0.10 I/Ino Limit value diff-current supervision -CZ
6310 DIF SUP mode BZ Monitoring alarm only
blocking
block./release
blocking Diff-current supervision mode -BZ
6311 DIF SUP mode CZ Monitoring alarm only
blocking
block./release
alarm only Diff-current supervision mode -CZ
6312A ZERO CR SUPERV Monitoring ON
OFF
ON Zero crossing supervision
6313A I> ZERO CR Monitoring 0.15 .. 4.00 I/Ino 0.50 I/Ino Threshold for zero crossing supervi-
sion
6315 CB SUP TIME Monitoring 1.00 .. 180.00 sec 7.00 sec CB supervision time
6316 I> MAN TRIP Monitoring 0.00 .. 2.50 I/In; ∞ 0.05 I/In Limit value for circuit breaker test
6317 T-TRIP-Rel sup Monitoring 0.06 .. 1.00 sec 0.06 sec Supervision bin. input TRIP-Release
6318 CTRL REL BU Protec. general released
blocked
released Control release for bay units
6320A EF charact. Protec. general released
blocked
blocked Earth fault characteristic switchover
6401A fault rec mode Osc. Fault Rec. global
central
decentralized
central Mode of fault recording
6404 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform Capture
Record
6405 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.20 sec Captured Waveform Prior to Trigger
6406 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.20 sec Captured Waveform after Event
6407 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.40 sec Capture Time via Binary Input
Addr. Setting Title Function Setting Options Default Setting Comments
