Technical Data
322
7SS52 V4 Manual
C53000-G1176-C182-3
(up to 8 fault records)
Capture Time max. 5s (total)
9.2.13 User-Configurable Functions (CFC)
Function Module Comment
ABSVALUE Formation of absolute value
ADD Addition
ALARM Alarm
AND AND gate
BLINK Flash Block
BOOL_TO_CO Boolean to command, conversion
BOOL_TO_DI Boolean to double-point indication, conversion
BOOL_TO_IC Boolean to internal single-point indication, conversion
BUILD_DI Generation of double-point indication
CMD_CHAIN Switching sequence
CMD_CANCEL Cancel command
CMD_INF Command information
COMPARE measured value comparison
CONNECT Connection
D_FF D-Flipflop
D_FF_MEMO D-Flipflop with preservation of information following restart
DI_GET_STATUS Information status double point indication, decoder
DI_SET_STATUS Double point indication with status, encoder
DI_TO_BOOL Double-point indication to Boolean, conversion
DIV Division
DM_DECODE Decoding of double-point indication
DYN_OR Dynamic OR gate
LIVE_ZERO Live zero monitoring, non-linear characteristic
LONG_TIMER Timer (max. 1193 h)
LOOP Signal feedback
LOWER_SETPOINT Value below lower limit
MEMORY data memory
MUL Multiplication
MV_GET_STATUS Information status measured value, decoder
MV_SET_STATUS Measured value with status, encoder
NAND NAND gate
NEG Negator
NOR NOR gate
OR OR gate
REAL_TO_INT Adapter
REAL_TO_UINT Real after U-Int, adapter
RISE_DETECT Flankendetektor
RS_FF RS Flipflop
RS_FF_MEMO Status memory for restart
SI_GET_STATUS Information status single point indication, decoder
SI_SET_STATUS Single point indication with status, encoder
SQUARE_ROOT Square-root extraction
SR_FF SR Flipflop
SR_FF_MEMO Status memory for restart
ST_AND AND gate with status
