Appendix
398
7SS52 V4 Manual
C53000-G1176-C182-3
A.16 Marshalling - Bay Unit 7SS523
When the device is delivered, annunciations are marshalled to the binary inputs, re-
lays, and LEDs for the maximum scope. The functional keys are pre-assigned. The
marshalling can be found in Table A-26, page 398 to Table A-30, page 400.
Table A-27 Default setting function keys
Table A-26 Marshalling of the binary inputs of the bay unit 7SS523
Address 1st display line 2nd display line FNo. Comment
6101 BINARY INPUT1 >Isolator1on NO 7601 >Isolator 1 - position closed
6102 BINARY INPUT 2 >Isolator1off NO 7602 >Isolator 1 - position open
6103 BINARY INPUT 3 >Isolator2on NO 7603 >Isolator 2 - position closed
6104 BINARY INPUT 4 >Isolator2off NO 7604 >Isolator 2 - position open
6105 BINARY INPUT 5 >Isolator3on NO 7605 >Isolator 3 - position closed
6106 BINARY INPUT 6 >Isolator3off NO 7606 >Isolator 3 - position open
6107 BINARY INPUT 7 >Isolator4on NO 7607 >Isolator 4 - position closed
6108 BINARY INPUT 8 >Isolator4off NO 7608 >Isolator 4 - position open
6109 BINARY INPUT 9 >Isolator5on NO 7609 >Isolator 5 - position closed
6110 BINARY INPUT 10 >Isolator5off NO 7610 >Isolator 5 - position open
6111 BINARY INPUT 11 >CBF L1 NO 7611 >Circuit breaker failure start phase L1
6112 BINARY INPUT 12 >CBF L2 NO 7612 >Circuit breaker failure start phase L2
6113 BINARY INPUT 13 >CBF L3 NO 7613 >Circuit breaker failure start phase L3
6114 BINARY INPUT 14 >CB man.close NO 7618 >Circuit breaker manual close
6115 BINARY INPUT 15 >CBF release NO 7615 >Circuit breaker failure release
6116 BINARY INPUT16 >CB Test NO 1156 >CB test start
6117 BINARY INPUT 17 >CB OFF NO 7617 >Circuit breaker open
6118 BINARY INPUT 18 not marshalled NO 1 No function assigned to this input
6119 BINARY INPUT 19 >CB not ready NO 7619 >Circuit breaker not ready
6120 BINARY INPUT 20 >Bay o.of ser NO 7620 >Bay out of service
NO: NO contact (active when energized)
NC: NC contact (active when not energized)
Function
key
Function
F1 Bay out of service
F2 CB test trip
F3 Maintenance of bay
F4 Transformer polarity reversal
