A.1.3 Accessories
Table A-3 Selection and ordering data for bay unit 7SS525
Order No.
Distributed busbar and breaker failure protection
SIPROTEC 7SS52 V4
BAY UNIT
7 S S 5 2 5 ❏ -5FA01-❏ AA 1
System version
50/60 Hz V3.* 5
Rated current at 50/60 Hz
1 A
5 A
1
5
Rated auxiliary voltage of converters
DC 48 to 250 V 5
Mechanical design in casing
in casing 7XP20 for flush mounting without plastic cover F
Ancillary functions
without
with overcurrent time protection
0
1
Table A-4 Accessories for Central Unit
Accessories
The following accessories are contained in the delivery of
the central unit:
• CD with firmware, manuals, labeling software
• Extraction handle for printed circuit boards
• FO Simplex indoor cable, length 0.2 m (2 pieces)
• FO coupler
• Self-adhesive labeling film
• Torx-socket wrench insert T8, T10, T20
• Buffer battery (see also Table A-6, page 339)
• Plastic rings for FO cables
A plastic bag that is attached to the rear of the device con-
tains the following accessories: • Plug-in jumpers for boards
Upgrade kit for EN100 module (release FF and higher) C 5 3 2 0 7 - A 3 5 1 - D 6 7 7 - 1
Spacer angles for central unit with mounting sketch C 5 3 2 0 7 - A 3 6 1 - B 7 0 1 - 1
Extraction handle, coding plug (10 x 2,54 mm + 25 x 5,08
mm), FO damping rings, FO test lead, FO plug-in connector
and CD with manual
C 5 3 2 0 7 - A 3 6 1 - D 7 0 2 - 1
PO damping rings (120 pcs.) as well as coding and test
plugs (plug 10 x 2,54 + 25 x 5,08 mm) C 5 3 2 0 7 - A 3 6 1 - D 7 0 3- 1
Coding plugs (100 pcs. 5,08 mm) C 5 3 2 0 7 - A 3 6 1 - D 7 0 4- 1
