Configuration
62
7SS52 V4 Manual
C53000-G1176-C182-3
4.3.9 Creating and Inserting Typicals.
An arrangement of different elements in the substation chart can be saved as a so-
called Typical. This Typical may then be inserted anywhere else in the substation
chart or into other charts.
To save elements as Typical you must:
 Select all elements in the chart you wish to save together as Typical.
 Click Edit →Save Graphic/Typical as on the menu bar. The Save as dialog box
opens.
 Enter a name for the Typical file. A Typical file has the extension .sst.
 Select the location where you want to save the Typical file.
 Click OK to apply the settings and to close the dialog box. The elements are saved
to a file in the form of a Typical.
To insert a Typical you must:
 Click Edit →Insert Graphic/Typical from on the menu bar. The Open dialog box
pops up.
 Select the drive of the Typical file from the Browse drop-down list box.
 Select a folder in the drop-down list box. You will find the supplied template files in
the folder SSTypicals.
 All available files with the extension .sst are displayed in the box. Select the name
of the Typical file you wish to open.
 Click OK to open the Typical file and to close the dialog box.
 Left-click into the chart to insert the Typical.
4.3.10 Saving the Substation Chart
You must explicitly save the modifications you have made to a chart.
To save the changes in the active chart you must:
 Click Chart →Save on the menu bar.
 Alternatively, you can click the button on the Standard toolbar.
Note
Unlike a Typical a Template represents an entire substation chart which may be com-
posed of Typicals. Templates may also be saved for reuse.
