Integrated Operation of the Bay Unit
179
7SS52 V4 Manual
C53000-G1176-C182-3
5.11.3 Settings of the Bay Unit
Addr. Setting Title Setting Options Default Settings Comments
7101 LANGUAGE DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
ITALIANO
PYCCK.
ENGLISH Operating language
7120 OPER.1st L. IL1, IL2, IL3, IE
I-DIFF. L1, I-DIFF. L2,
I-DIFF. L3
I-RESTR. L1, I-RESTR. L2,
I-RESTR. L3
IL1 Display of measured values in
the 1st line of the quiescent-
state indication in 4-line mode
7121 OPER.1st L. PRIMARY
SECONDARY
NORMALIZED
SECONDARY Display of measured values in
the 1st line as primary or sec-
ondary (percent) values
7122 OPER.2nd L. IL1, IL2, IL3, IE
I-DIFF. L1, I-DIFF. L2,
I-DIFF. L3
I-RESTR. L1, I-RESTR. L2,
I-RESTR. L3
IL2 Display of measured values in
the 2nd line of the quiescent-
state indication in 4-line mode
7123 OPER.2nd L. PRIMARY
SECONDARY
NORMALIZED
SECONDARY Display of measured values in
the 2nd line as primary or sec-
ondary (percent) values
7124 OPER.3rd L. IL1, IL2, IL3, IE
I-DIFF. L1, I-DIFF. L2,
I-DIFF. L3
I-RESTR. L1, I-RESTR. L2,
I-RESTR. L3
IL3 Display of measured values in
the 3rd line of the quiescent-
state indication in 4-line mode
7125 OPER.3rd L. PRIMARY
SECONDARY
NORMALIZED
SECONDARY Display of measured values in
the 3rd line as primary or sec-
ondary (percent) values
7126 OPER.4th L. IL1, IL2, IL3, IE
I-DIFF. L1, I-DIFF. L2,
I-DIFF. L3
I-RESTR. L1, I-RESTR. L2,
I-RESTR. L3
IE Display of measured values in
the 4th line of the quiescent-
state indication in 4-line mode
7127 OPER.4th L. PRIMARY
SECONDARY
NORMALIZED
SECONDARY Display of measured values in
the 4th line as primary or sec-
ondary (percent) values
