Settings

−

Central Unit

353

7SS52 V4 Manual

C53000-G1176-C182-3

1) Delivery setting

Table A-12 Jumper settings for different control voltages of the binary inputs of the

EAZ module

Setting for nominal control voltage

Name 24 V 60 V 110 V

220 V

BI1 to BI5 (on module D-CPU, Table A-15, page 355)

BI6 X31 X21 X11 -

BI7 X32 X22 X12 -

BI8 X33 X23 X13 -

BI9 X34 X24 X14 -

BI10 X35 X25 X15 -

BI11 X36 X26 X16 -

BI12 X37 X27 X17 -

Table A-13 Coding switch setting for the EAZ module

Switch S1 Position

S1.1 off

S1.2 on

S1.3 off

S1.4 off
