Appendix
388
7SS52 V4 Manual
C53000-G1176-C182-3
7672 IDL1 = BZ: Differential current phase L1 M
7673 IDL2 = BZ: Differential current phase L2 M
7674 IDL3 = BZ: Differential current phase L3 M
7675 ISL1 = BZ: Stabilising current phase L1 M
7676 ISL2 = BZ: Stabilising current phase L2 M
7677 ISL3 = BZ: Stabilising current phase L3 M
7678 IDL1 = BZ: Differential current phase L1 M
7679 IDL2 = BZ: Differential current phase L2 M
7680 IDL3 = BZ: Differential current phase L3 M
7681 ISL1 = BZ: Stabilising current phase L1 M
7682 ISL2 = BZ: Stabilising current phase L2 M
7683 ISL3 = BZ: Stabilising current phase L3 M
7684 IL1= Current in phase L1 = M
7685 IL2= Current in phaset L2 = M
7686 IL3= Current in phase L3 = M
7687 IE= Earth current IE = M
7689 TR flt,Trp.po Relay control circuit flt.,trip possib. on/off OT 1 GI 194 144
7690 >Blk.BF of BB >Block.BF (ex.start) of whole busbar on/off on IOT
7691 TR1flt,Trp.np Relay1 control circuit flt.,no trip pos on/off OT 1 GI 194 145
7692 TR2flt,Trp.np Relay2 control circuit flt.,no trip pos on/off OT 1 GI 194 146
7693 TR3flt,Trp.np Relay3 control circuit flt.,no trip pos on/off OT 1 GI 194 147
7694 TR4flt,Trp.np Relay4 control circuit flt.,no trip pos on/off OT 1 GI 194 148
7695 TR5flt,Trp.np Relay5 control circuit flt.,no trip pos on/off OT 1 GI 194 149
7696 Annunc. 1 User defined annunciation 1 on/off OT
7697 Annunc. 2 User defined annunciation 2 on/off OT
7698 Annunc. 3 User defined annunciation 3 on/off OT
7699 Annunc. 4 User defined annunciation 4 on/off OT
FNo. Short Text Logical Function Log Buffers Configurable
in Matrix
IEC 60870-5-103
Event Log On/Off
Measured Value
Trip (Fault) Log On/Off
Binary Input I
Binary Output O
(LED, alarm relay)
Trip Relay T
Data Unit
Compatible Annunciation
General Interrogation
Annunc. for Fault Rec. Buffer
(Tagged)
Type (p: Corresponds to
parameter “Function type“)
Information Number
