Appendix
390
7SS52 V4 Manual
C53000-G1176-C182-3
10449 Trip command BBP 177.1342 Trip command for $03 L1 BZnn
177.1343 Trip command for $03 L2 BZnn
177.1344 Trip command for $03 L3 BZnn
10436 Trip command BF 177.1352 Trip command BF for $03 phase L1 BZnn
177.1353 Trip command BF for $03 phase L2 BZnn
177.1354 Trip command BF for $03 phase L3 BZnn
177.1341 Trip command for $03
177.1342 Trip command for $03 L1 BZnn
177.1352 Trip command BF for $03 phase L1 BZnn
177.1343 Trip command for $03 L2 BZnn
177.1353 Trip command BF for $03 phase L2 BZnn
177.1344 Trip command for $03 L3 BZnn
177.1354 Trip command BF for $03 phase L3 BZnn
10446 Trip command L1 177.1342 Trip command for $03 L1 BZnn
177.1352 Trip command BF for $03 phase L1 BZnn
10447 Trip command L2
177.1343 Trip command for $03 L2 BZnn
177.1353 Trip command BF for $03 phase L2 BZnn
10448 Trip command L3
177.1344 Trip command for $03 L3 BZnn
177.1354 Trip command BF for $03 phase L3 BZnn
10450 Trip repeat BU
176.1071 Trip repeat $00 phase L1 BUnn
176.1072 Trip repeat $00 phase L2 BUnn
176.1073 Trip repeat $00 phase L3 BUnn
10433 Breaker Failure/Transfer Trip 176.1082 Breaker failure/Transfer trip $00 BUnn
10434 Timing error BF input 176.1091 Timing error BF input $00 L1 BUnn
176.1092 Timing error BF input $00 L2 BUnn
176.1093 Timing error BF input $00 L3 BUnn
176.1096 Timing error BF input $00 3pole BUnn
10435 Timing error BF release 176.1101 Timing error BF release $00 1pole BUnn
176.1102 Timing error BF release $00 3pole BUnn
10437 Timing error BF impulse input 176.1104 Timing error BF impulse input $00 BUnn
10453 Bay out of service
176.1061 Bay $00 out of service BUnn
10454 Maintenance of bay
176.1062 $00 isolator maintenance BUnn
10471 Isolator oper. prohibited 176.1062 $00 isolator maintenance BUnn
177.1338 Blocked Trip command $03 BZnn
177.1348 Blocked BF protection for $03 BZnn
10455 Bay unit failure
176.1063 Bay unit $00 failure BUnn
10451 Transformer reversed in polarity 176.1195 Transformer reversed in polarity $00 BUnn
10456 Circuit breaker fault
176.1136 Circuit breaker fault $01 BUnn
Group Alarm Alarm
FNo. Description FNo. Logical function Relates to
