Matching the Control Voltage for the Binary Inputs and Inserting the Buffer Battery

7SS52 V4 Manual

C53000-G1176-C182-3

Table 3-3 Control voltage for the binary inputs on the EFE (bay unit) in relation to the fitted

jumper

Control voltage setting

Name 24 V 60 V 110 V 220 V

BI 1 X37 X36 X35 -

BI 2 X40 X39 X38 -

BI 3 X43 X42 X41 -

BI 4 X46 X45 X44 -

BI 5 X49 X48 X47 -

BI 6 X52 X51 X50 -

BI 7 X55 X54 X53 -

BI 8 X58 X57 X56 -

BI 9 X61 X60 X59 -

BI 10 X64 X63 X62 -

BI 11 X67 X66 X65 -

BI 12 X70 X69 X68 -

BI 13 X73 X72 X71 -

BI 14 X76 X75 X74 -

BI 15 X79 X78 X77 -

BI 16 X82 X81 X80 -

BI 17 X85 X84 X83 -

BI 18 X88 X87 X86 -

BI 19 X91 X90 X89 -

BI 20 X94 X93 X92 -
